Marantz Cinema 50

POWER AMPLIFIER
Number of Powered Channels: 9
Power Output (8 ohms, 20 Hz – 20 kHz, 0.08% 2ch Drive): 110 W
Power Output (8 ohms, 20 Hz – 20 kHz, 0.05% 2ch Drive): –
Power Output (6 ohms, 1 kHz, 0.7% 2ch Drive): 150 W
Power Output (6 ohms, 1kHz, 10% 1ch Drive): 220W
Discrete Power Amplifier: Yes
Amplifier Topology: Class A/B
Current Feedback Topology: Yes
Bi-Amp Drive: assignable

MULTICHANNEL SURROUND TECHNOLOGIES
DTS: DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
Dolby: Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Other: IMAX Enhanced, Auro-3D, 360 Reality Audio, MPEG H, Multichannel Stereo
Max Number of Processing (Preamp) Channels: 11.4

Inputs/Outputs
Composite inputs/outputs: 0/0
Component input / output: 0/0
HDMI inputs/outputs: 6 / 3
Multi-Room Video Out via HDMI: No / Yes
Analog In / Fixed Level Out: 6 in / 0 out
Phono (MM) input: Yes
Digital In: Optical / Coaxial: 2 / 2
Multi-room output: analogue / digital: 1 /0
Multichannel Preamp Out: 11.4
Subwoofer output: 4 (independent)
7.1 Multi-channel input: Yes
Number of speaker terminals: 11
Speaker A/B: assignable
Multi-room speaker connections: assignable
Front inputs: USB-A
USB Audio: Yes / No / No
FM Tuner with RDS: No
DAB+ tuner: no

HDMI
Total HDMI Inputs / No. Support 8K: 6 / 6
HDCP2.3 support: Yes
HDMI outputs Main Zone / Zone: 2 / 1
Analog to HDMI Video Conversion: No
HDMI upscaling: 1080P/4K to 8K
Audio return channel for TV sound (ARC): eARC
Video Dynamic Range: HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes
Variable Refresh Rate / Quick Frame Transport: Yes / Yes / No
HDMI pass-through in standby mode: Yes
HDMI Control (CEC): Yes
DSD Audio over HDMI: Yes
Auto LipSync: Yes

PERFORMANCE TECHNOLOGIES
Copper Plated Chassis: No
Toroidal Power Supply Transformer: No
Hyper Dynamic Amplifier Modules (HDAM) (List version): Yes
Pure Direct Mode: Yes
Gold Plated RCA Terminals: Yes
Clock Jitter Reducer: Yes
Acoustic / Room Correction
Audyssey: MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
Audyssey LFC: Yes / Yes
Dirac Live Support: Yes
Variable Crossover: Yes
Optimized Bass Redirection: Yes
Bass Sync: Yes

MUSIC FILE SUPPORT
Lossy format: MP3 / WMA / AAC
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/31
DSD Audio: 2.8MHz / 5.6MHz
Gapless playback: FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2: Yes
Network Audio Sharing: Yes

STREAMING SERVICES
HEOS Multi-room and Streaming: Yes
AirPlay Audio Streaming: AirPlay 2
Internet Radio: TuneIn
Spotify*: Spotify Connect
Pandora: Yes
SiriusXM: Yes
Other Streaming Services *: Amazon Music HD / Amazon Music / TIDAL / Deezer / Napster / Soundcloud / Mood Mix
Roon tested: Yes

NETWORK CONNECTIVITY
Ethernet Ports: Yes
Wi-Fi (include version / band): Yes
Bluetooth (Include version): Yes
Bluetooth Re-transmit for Bluetooth headphones: Yes

SMART HOME INTEGRATION AND CONTROL
Voice Assistant Compatibility: Alexa / Google Voice Assistant / Apple HomePod
App for Smart Phones & Tablets (iOS & Android): Marantz AVR App
HEOS Multi-Room Integrated: Yes
HEOS Link Compatibility: IR/ IP: Yes / Yes
Multi room zones: 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: 2 Ch / 2 Ch / Yes / Yes
Zone Audio Output: Speaker / Preout: Yes / Yes
Zone HDMI Output from HDMI Source: Yes
Control Connectivity: IP Control / RS232 Control / Web Control / App Control
IR Flasher In: Yes
Marantz Remote Bus: Yes
DC trigger output: 1
HDMI Diagnostics: Yes
Other
Front display: port hole OLED
GUI languages: 9
Installation Wizard: Yes
Smart Select on Remote: Yes
Firmware update via network / USB: Yes / Yes
ECO Mode: Yes
Auto Power Off: Yes
Sleep Timer: Yes

General
Metal front: Yes
Remote control: RC-049SR
Power consumption in W: 680
Power Consumption No-Sound (ECO on/off) in W: 60W / 100W
Standby power consumption in W: 0.2
CEC Standby Power Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
Maximum Dimensions (W x D x H):
Antenna horizontal in mm: 442 x 404 x 165
Antenna vertical in mm: 442 x 404 x 235
s/o antenna in mm: 442 x 392 x 165
Weight in kg: 13.5
